| Sealing Style | 4 Side Seal |
| Speed | 50 - 70 Strokes / minute maximum (Depends upon the type of product & quantity to be filled) |
| No. of Tracks | Depends upon the width of the pouch |
| Laminate Specification | Length 2000 mm Roll Dia – 600mm. max. Reel Core I.D.- 150/76 mm |
| Filling Capacity | 10gm-100gm |
| Product To Be Packed | Any type of free flowing powder |
| Sealing Drives | Mechanical – Cam driven with individual sealing jaw setting |
| Filling Mechanism | Slide Filler |
| Perforation and Cutting | As per customer requirement |
| Laminate Roll Unwind | Motor driven – Bonfiglioli Geared Motor. |
| Laminate Draw Off System | PLC based Servo Driven. |
| Control | Through Touch Screen Panel (HMI) |
| Laminate Tracking System | E+L web aligner – Digital. |
| Main Control Panel | Air cooled panel – BCH make or Rittal |
| Contact Parts | SS 304 / 316 |
| Indirect Contact Parts | SS 304 / 316 |
| Batch Cutting | Can be programmed through PLC |
| Mat Format | In built feature of the Machine. |
| Electrical Spec. | Main Motor – 2.2 KW, 3 Phase, 415 V Connected load – 14 Kw. Consumption – 11 Kw. PLC controlled Operations RTD module with PLC for Temperature controllers |
| Layout Dimensions | Length -3200 mm Width – 2600 mm Height – 2100 mm |
| Machine Weight | Net Weight – 3500 kgs. Gross weight – 4000 kgs. |
| Pneumatics | FESTO or equivalent. |
| Machine Efficiency | 90%* |
| Scrap Rate | Less than 2%* |
| Machine Colour | Shell Grey – Powder coated. |
| Weight Variation | Within +/- 1%** of the filled quantity |
